ALTERNATOR/STARTER CLUTCH
SERVICE INFORMATION
ALTERNATOR/STARTER CLUTCH
GENERAL
• This section covers service of the alternator and starter clutch. All service can be done with the engine installed in the frame.
• For alternator inspection (page 21-9).
• For CKP sensor inspection (page 5-7).
• For starter motor service (page 6-5).

TROUBLESHOOTING

Starter motor turns, but engine does not turn
• Faulty starter clutch
• Damaged starter reduction gear/shaft
• Damaged starter idle gear/shaft
• Damaged or faulty starter motor pinion gear
• Damaged starter driven gear

11-2
