DUAL CLUTCH TRANSMISSION (DCT) (CRF1000D)
Refer to
DTC Function Failure Symptom/Fail-safe function
page
No.1 clutch oil pressure high • Gearshift function does not work
• No.1 clutch EOP sensor malfunction
62-1 • Faulty clutch oil circuit
• No.1 linear solenoid valve malfunction
• Faulty PCM
No.1 clutch oil pressure high (Prevention of motorcycle • Gearshift function does not work 13-45
creeps)
• No.1 clutch EOP sensor malfunction
62-2 • Faulty clutch oil circuit
• No.1 linear solenoid valve malfunction
• Faulty PCM
No.2 clutch oil pressure malfunction (at clutch initial • Gearshift function does not work
diagnosis)
63-1 • No.2 clutch EOP sensor malfunction
• Faulty clutch oil circuit
• Faulty PCM
No.2 clutch no oil pressure • Gearshift function does not work
• No.2 clutch EOP sensor malfunction
63-2 • Faulty clutch oil circuit
• No.2 linear solenoid valve or its circuit malfunction
• Faulty PCM
No.2 clutch oil pressure degradation • Gearshift function does not work 13-45
• No.2 clutch EOP sensor malfunction
63-3 • Faulty clutch oil circuit
• No.2 linear solenoid valve malfunction
• Faulty PCM
No.2 clutch oil pressure canceling malfunction • Gearshift function does not work
• No.2 clutch EOP sensor malfunction • Engine does not operate
• Faulty clutch oil circuit
63-4 • Loose or poor contact of the No.2 linear solenoid valve
and clutch EOP sensor connectors
• No.2 linear solenoid valve or its circuit malfunction
• Faulty PCM
No.2 clutch oil pressure high • Gearshift function does not work
• No.2 clutch EOP sensor malfunction
64-1 • Faulty clutch oil circuit
• No.2 linear solenoid valve malfunction
• Faulty PCM
No.2 clutch oil pressure high (Prevention of motorcycle • Gearshift function does not work 13-45
creeps)
• No.2 clutch EOP sensor malfunction
64-2
• Faulty clutch oil circuit
• No.2 linear solenoid valve malfunction
• Faulty PCM
Front and rear wheel speed signal malfunction • Gearshift function does not work
• Front wheel speed sensor or its circuit malfunction
65-1 • VS sensor or its circuit malfunction 13-46
• Faulty ABS modulator
• Faulty PCM
Rear wheel speed sensor no signal • Gearshift function does not work
• Rear wheel speed sensor or its circuit malfunction
• Loose or poor contact of the rear wheel speed sensor
connector
66-1 4-33
• Electromagnetic interference at rear wheel speed sensor
• Faulty ABS modulator
• Faulty rear pulser ring
• Faulty PCM
Front wheel speed sensor no signal • Gearshift function does not work
• Front wheel speed sensor or its circuit malfunction
• Loose or poor contact of the front wheel speed sensor
connector
67-1 • Electromagnetic interference at front wheel speed 4-35
sensor
• Faulty ABS modulator
• Faulty front pulser ring
• Faulty PCM

13-13
