DUAL CLUTCH TRANSMISSION (DCT) (CRF1000D)
3. VS Sensor Condition Inspection
Remove the VS sensor (page 4-42).
Check the VS sensor for damage or contaminated.
Is the VS sensor in good condition?
YES – Replace the PCM with a known good one
(page 4-39) and recheck.
NO – Replace the VS sensor with a known good
one and recheck.

DTC 68-1 (No.1 CLUTCH OPERATION
MALFUNCTION; CLUTCH SLIPS)

1. DTC Recheck
Erase the DTC (page 13-9).
Test-ride the motorcycle above 20 km/h (12 mph)
for more than 20 seconds.
Stop the engine.
Check the DTC with the MCS.
Is DTC 11-1 indicated?
YES – Refer to DTC 11-1 troubleshooting (page
4-21).
NO – GO TO STEP 2.
2. Clutch Condition Inspection
Disassemble and check the No.1 clutch assembly
(page 13-63).
Is the No.1 clutch in good condition?
YES – Replace the PCM with a known good one
(page 4-39) and recheck.
NO – Replace the faulty part.

DTC 69-1 (No.2 CLUTCH OPERATION
MALFUNCTION; CLUTCH SLIPS)
1. DTC Recheck
Erase the DTC (page 13-9).
Test-ride the motorcycle above 20 km/h (12 mph)
for more than 20 seconds.
Stop the engine.
Check the DTC with the MCS.
Is DTC 11-1 indicated?
YES – Refer to DTC 11-1 troubleshooting (page
4-21).
NO – GO TO STEP 2.
2. Clutch Condition Inspection
Disassemble and check the No.2 clutch assembly
(page 13-63).
Is the No.2 clutch in good condition?
YES – Replace the PCM with a known good one
(page 4-39) and recheck.
NO – Replace the faulty part.

13-47
